DX SABERS INSTRUCTIONS: HOW TO USE TWO BUTTON OMNIPIXEL/RGBX



ASSEMBLY: Take the small bag with the L shaped allen key wrench and the very tiny fastening screws. There are small holes around the top of your lightsaber hilt (handle). Put your blade into your DX Saber Hilt (handle) and screw the small screws into the holes until they are nice and tight against the blade. Then you are ready to go!!

 Feature overview

16 Soundfont Sets: Luke/Obi-wan/Darth Vader/Anakin/Darth Maul/Ahsoka Tano/Cal Kestis/Yoda/Kylo Ren/Starkiller/Darksaber/Dooku/Revan/Leia/Emperor/Dark-Side Rey
12 Blade colors: Red/Blue/Yellow/Cyan/Ice-Blue/Green/Pink/Orange/Purple/Peak-Green/Rose/White
4 sets blade effect: Ghost/Stable/Blaster/Pulse
Button names
  1. PWR (if buttons are the same size, then PWR is the top button. Otherwise, it's the larger button if they are different sizes.)
  2. AUX (if buttons are the same size, then AUX is the bottom button. Otherwise, it's the smaller button if they are different sizes.)
Turning on/off
Wake mode
This saber has what is called "Wake mode" which is a low-power mode in between being completely off and having the blade actually on (ignited).
To enable Wake mode, hold the PWR button for 3 seconds.
To turn it back off from Wake mode, hold PWR button for 8 seconds or simply leave alone for 20 minutes, after which it will automatically turn off to save power.
Igniting/Activating The Blade
While in Wake mode, tap the PWR button to turn the saber blade on. (Holding the button down too long will trigger other commands instead of powering up the blade.)
GESTURE CONTROL: give a sharp controlled twist around the axis of the blade while pointing it straight out to turn it on with style. This may take some practice to master, so give it a few tries if it doesn't work right away; you may not have used the appropriate angle, force, or speed.
Powering Down The Blade
Tap the PWR button to turn the saber blade off; the saber will still be in Wake mode.
GESTURE CONTROL: give a sharp controlled twist around the axis of the blade while pointing it straight out to turn it off with style. This may take some practice to master, so give it a few tries if it doesn't work right away; you may not have used the appropriate angle, force, or speed.


Changing Colors
GESTURE CONTROL: while the blade is on, hold the AUX button, point the blade downwards, then give a sharp controlled twist around the axis of the blade to toggle to the next color quickly. This may take some practice to master, so give it a few tries if it doesn't work right away; you may not have used the appropriate angle, force, or speed.
Lightsaber effects (saber must be turned on)
Blaster sound: Tap the AUX button.
Lock-up loop: Press the AUX button for 1 second and release your finger to activate Lock-up. Press it again to end the effect.
Flash-on-clash: The saber will automatically flash white and emit a sound when it hits another surface. To turn this effect off, while the blade is on hold the PWR button for 1 second to toggle Flash-on-clash on/off. (If the blade is off, this will toggle volume levels instead.)
Blade Effect Switching
This model has 4 blade effect sets: Ghost/Stable/Blaster/Pulse
GESTURE CONTROL: while the blade is on, hold the AUX button, point the blade upwards, then give a sharp controlled twist around the axis of the blade to toggle to the next blade effect set. This may take some practice to master, so give it a few tries if it doesn't work right away; you may not have used the appropriate angle, force, or speed.
Volume Adjustment
While blade is off (in Wake mode), hold the PWR button for 1 second to adjust the volume between High, Low, and Mute. (If the blade is on, this will toggle Flash-on-clash on/off instead.)
Sound Font Switching
While blade is off (in Wake mode), press the AUX button to select the next sound font.
GESTURE CONTROL: while the blade is off (in Wake mode), hold the AUX button, point the blade upwards, then give a sharp controlled twist around the axis of the blade to switch to a different sound font. This may take some practice to master, so give it a few tries if it doesn't work right away; you may not have used the appropriate angle, force, or speed.
Background Music
This model comes with background music files that you can toggle with gesture controls.
GESTURE CONTROL: while the blade is off (in Wake mode), hold the AUX button, point the blade downwards, then give a sharp controlled twist around the axis of the blade to toggle music tracks. This may take some practice to master, so give it a few tries if it doesn't work right away; you may not have used the appropriate angle, force, or speed.
Charging
When the battery runs low, a voice will sound to inform you the battery is low. Insert the charging cable in the DC port. The hilt will have a "pulsing" light indicating that it is charging. Once it is fully charged, the light will either turn off or remain lit and steady to indicate a full charge.
Symptoms of low battery
If you haven't charged it recently, the saber may flash on clash with a red tinge; if you don't notice this or ignore it long enough, the saber will turn off automatically and no longer be powered on OR in wake mode until recharged.
